High Brightness Industrial Lcd Screen 19'' 1280×1024 TFT LCD G190EAN01.5 For Outdoor

Product Categories

N&S ELECTRONIC CO., LIMITED

Contact Now

Brand Name : AUO

Model Number : G190EAN01.5

Certification : ISO9001

Place of Origin : Japan

MOQ : 1

Payment Terms : T/T, Western Union,Escrow 10(we pay hkinventory escrow fee) ,Paypal

Supply Ability : 500PCS

Delivery Time : 1-3 Working Days

Packaging Details : Antistatic bag, Bubble Bag, Foam Box and Carton Box

Size : 19 Inch

Screen Type : LCM , a-Si TFT-LCD

Luminance : 700 (Typ.)(cd/m²)

Viewing Angle : 89/89/89/89 (Typ.)(CR≥10)

Contrast Ratio : 1000 : 1 (Typ.) (TM)

Color Depth : 16.7M 72% NTSC

Signal Type : LVDS (2 ch, 8-bit) , Connector , 30 pins

Touchscreen : Without

Contact Now

1. General Description

2.Display Characteristics

Items	Unit	Specifications
Screen Diagonal	[inch]	19.0"
Active Area	[mm]	376.32 (H) x 301.06 (V)
Resolution		1280(x3) x 1024
Pixel Pitch	[mm]	0.294 (per one triad) x 0.294
Pixel Arrangement		R.G.B. Vertical Stripe
Display Mode		Normally Black, AHVA
Nominal Input Voltage VDD	[Volt]	+5.0 V
Power Consumption	[Watt]	Logic: max. 4 W@ white pattern BL power: max. 25.2 W
Weight	[Grams]	1700 +/- 150g
Physical Size	[mm]	396 (H) x 324 (V) x 15.3 (D) (Typ)
Electrical Interface		LVDS
Surface Treatment		Anti-Glare treatment
Support Color		16.7M colors (8bit)
Temperature Range Operating Storage (Non-Operating)	[^oC] [^oC]	0 to +50 -20 to +60
RoHS Compliance		Yes

3.Optical Characteristics

Item	Unit	Conditions		Min.	Typ.	Max.	Note
White Luminance	cd/m²	Center point (at LED= 55mA)		560	700	---	1
Uniformity	%	9 points		80	---	---	2,3
Contrast Ratio	--			600	1000		4
Response Time	msec	Rising		-	13	18	5
		Falling		-	12	17
		Rising + Falling		-	25	35
Viewing Angle	degree	Horizontal CR >= 10	(Right)	85	89	---	6
		Horizontal CR >= 10	(Left)	85	89
		Vertical CR >= 10	(Upper)	85	89
		Vertical CR >= 10	(Lower)	85	89
Color / Chromaticity Coordinates (CIE 1931)	--	Red x		0.621	0.651	0.681
		Red y		0.313	0.343	0.373
		Green x		0.272	0.302	0.332
		Green y		0.581	0.611	0.641
		Blue x		0.125	0.155	0.185
		Blue y		0.045	0.075	0.105
		White x		0.283	0.313	0.343
		White y		0.299	0.329	0.359
Color Gamut	%			---	72%	---
