18.5 inch AUO LCD Panel Normally White G185XW01 V201 LCM 1366×768 Brightness 450

Product Categories
N&S ELECTRONIC CO., LIMITED
Contact Now

18.5 inch AUO LCD Panel Normally White G185XW01 V201 LCM 1366×768 Brightness 450

Brand Name : AU Optronics

Model Number : A070FW03 V1

Certification : ISO9001

Place of Origin : KOREA

MOQ : 1

Payment Terms : Western Union, T/T, MoneyGram, T/T

Supply Ability : 500PCS/DAY

Delivery Time : 1-3 Working Days

Packaging Details : Antistatic bag, Bubble Bag, Foam Box and Carton Box.

Active Area : 154.08×86.58 mm

Outline : 164.9×100 mm

Surface : Antiglare (Haze 5.5%)

Panel Type : a-Si TFT-LCD , LCM

Contact Now

Normally White G185XW01 V201 AUO 18.5 inch LCM 1366×768 Brightness 450

AUO G185XW01 V201 Mechanical Features

Screen Size : 18.5 inch
Pixel Features : Pixel Number Pixel Format Dot Pitch (H×V) Pixel Pitch (H×V)
1366(RGB)×768, WXGA RGB Vertical Stripe 0.100×0.300 mm 0.300×0.300 mm
Mechanical Size : Display Area (H×V) Bezel Opening (H×V) Overall Dimension (H×V) Overall Depth
409.8×230.4 mm 413.4×234.0 mm 430.4×254.7 mm 10.6 (Typ.) mm
Outline Features : Form Shape Aspect Ratio (H:V) Orientation Shape Style
Flat Rectangle Display 16:9 Landscape type -
Other Spec : Mass Panel Cover Surface Treatment
1.44Kgs (Max.) - Antiglare, Hard coating (3H)
Holes & Brackets : Side mounting holes (4-M3) on left, right bezel

AUO G185XW01 V201 Optical Features

Basic Information : Luminance Work Mode Contrast Ratio
450 cd/m² (Typ.) TN, Normally White, Transmissive 1000:1 (Typ.) (Transmissive)
Good View at Viewing Angle Response Time
- 85/85/80/80 (Typ.)(CR≥10) 3.5/1.5 (Typ.)(Tr/Td) (ms)
Dispaly Color : Gamut Support Color Color Coordinate
70% NTSC (CIE1931) 16.7M (6-bit + Hi-FRC) Wx:0.313; Wy:0.329
White Uniformity : 1.43/1.54 (Typ./Max.)(9 points)

AUO G185XW01 V201 Specification Source

Datasheet Referenced : File Number Version Language Issue Date
- Pre Ver0.0 English 2017 - 10 - 11
Panelook Latest Update : 2018-01-23 10:35


Packaging & Delivery
Packaging Details:
Safey package
Plastic trays inside
2 layes of cartons
Fragile sign on top
Can be customize 3.5 inch spare parts auo used lcd panel
Delivery Detail: 1-3 Working Days

Our Advantage :
>>Quality Guarantee:
Our LCD Panels are 100% original and brand new!
Warranty : 12 months
You can enjoy the real panels directly from the LCD panel brand distributor.
>>Packing Guarantee:
All the products are in original package from original factory directly, and all the LCD panel packages with labels and serial number!
>>Delivery Guarantee:
We have international logistic center in HK, so we can arrange fastest and most convenient delivery for you!
>>After-Sale service
We have many years good experience on display solution.
Any question, we will reply you within 12 hours.

Below are our other LCD panels stock for your easy reference:

Panel Model Brand Size Resolution
X139BLB01.0 AUO 1.39" 400×400
H381DLN01.0 AUO 3.8" 1080×1200
H497TLB01.4 AUO 5.0" 720×1280
H163QLN01.0 AUO 1.63" 320×320
H139BLN01.2 AUO 1.39" 400×400
H500TLB01.0 AUO 5.0" 720×1280

We also have other industrial LCD panels, pls contact to us for the further information
