New and original G140HAN01.0 AUO 14 inch LCM 1920×1080 for Instrial Application
AUO G140HAN01.0 Mechanical Details
| Pixel Features : |
Pixel Format |
1920(RGB)×1080 [FHD] |
Dot Pitch |
0.054×0.161 mm (H×V) |
| Configuration |
RGB Vertical Stripe |
Pixel Pitch |
0.161×0.161 mm (H×V) |
| Mechanical Size : |
Display Area |
309.14×173.89 mm (H×V) |
Bezel Area |
- |
| Outline Dim. |
319×190.76 mm (H×V) |
Outline Depth |
4.9/8.3 (Typ./Max.) mm |
| Outline Features : |
Form Factor |
Flat Rectangle Display |
Orientation |
Landscape type |
| Aspect Ratio |
16:9 (H:V) |
Shape Style |
- |
| Holes & Brackets : |
Without |
| Other Features : |
Weight |
TBD |
Surface |
Glare (Haze 0%), Hard coating (3H) |
AUO G140HAN01.0 Optical Details
| Basic Information : |
Brightness |
500 cd/m² (Typ.) |
Contrast Ratio |
800:1 (Typ.) (Transmissive) |
| Viewing Angle |
89/89/89/89 (Typ.)(CR≥10) |
Optical Mode |
AHVA, Normally Black, Transmissive |
| Viewing Direction |
Symmetry |
Response Time |
15/10 (Typ.)(Tr/Td) (ms) |
| Color Performance : |
Chromaticity |
Wx:0.313; Wy:0.329 |
Color Numbers |
262K (6-bit) |
| Color Gamut |
- |
Uniformity |
1.33 (Max.)(5 points) |
Shipment for the LCD Display Panels:
1. Safe & Professional package for our LCD panels.
2. We can ship to you by UPS/FEDEX/DHL/TNT and so on. Other shipping terms can also be arranged according to specific requirements.
3. We are not responsible for any accidents, delays or other issues that are the responsibility of the shipping service.
4. All our LCD panel will be tested pcs by pcs before been shipped out.
AUO G140HAN01.0 Backlight Details
| Back-light Features: |
Lamp Shape |
- |
Lamp Type |
WLED |
Life Time |
50K(Min.) (Hours) |
| Replacement |
- |
Amount |
- |
Position |
Edge light type |
| Interface Features : |
Type |
Included in panel signal interface |
Position |
- |
Lamp Driver |
With LED Driver |
| Driver Electrical : |
Voltage Input |
5.0/12.0/21.0V (Min./Typ./Max.) |
Current Input |
462mA (Typ.) |
| Consumption |
5.54/6.1W (Typ./Max.) |
Our service
1. Agent Brand:
* Our sourcing line contained but not limited to Samsung, LG, Sharp, AUO, Tianma, Chimei, Hannstar, Innolux, BOE and more bands tft lcd moulds from 2010, you can get the most competitive price for real products;
2. Quality to be guaranteed:
* All the panels are 100% original and brand new, no fake panels exists.Take the lcd screen from us, you can enjoy the real panels directly from original factory;
* Original package and Seal for batch orders, all the products are in original package from original factory directly, and all the LCD panels packages have labels and serial number, you can check them;
- Quickly delivery:
* We also have international logistic center in Hongkong to support your batch orders to be delivered from Hongkong directly.
- long-term partner:
* Products are sold to more than 20 countries.
- Super After-Sale service:
* One year warranty .
6. The best TFT LCD solution:
*more tft lcd model detail information for the LCD screens including size, resolution, brightness, operating temperature or life time etc in our web site.
Below are our other LCD panels stock for your easy reference:
| Panel Model |
Brand |
Size |
Resolution |
| X139BLB01.0 |
AUO |
1.39" |
400×400 |
| H381DLN01.0 |
AUO |
3.8" |
1080×1200 |
| H497TLB01.4 |
AUO |
5.0" |
720×1280 |
| H163QLN01.0 |
AUO |
1.63" |
320×320 |
| H139BLN01.2 |
AUO |
1.39" |
400×400 |
| H500TLB01.0 |
AUO |
5.0" |
720×1280 |
| X546DLB01.0 |
AUO |
5.5" |
1080×1920 |
| H546DLB01.1 |
AUO |
5.5" |
1080×1920 |
We also have other industrial LCD panels, pls contact to us for the further information
