10.4 inch TMS150XG1-10TB TFT Tianma LCD Displays Panel 800×600 for Desktop Monitor
TMS150XG1-10TB Specification
| Panel Model |
TMS150XG1-10TB |
| Panel Brand |
AVIC |
| Descrition |
a-Si TFT-LCD ,15.0 inch, 1024×768 |
| Panel Type |
a-Si TFT-LCD |
| Display Mode |
TN, Normally White, Transmissive |
| Active Area |
304.128×228.096 mm |
| Outline |
326.5×253.5×12 mm |
| Surface |
Antiglare |
| Contrast Ratio |
600:1 (Typ.) |
| Display Colors |
16.7M (6-bit + Hi-FRC) , CIE1931 60% |
| Response Time |
2/6 (Typ.)(Tr/Td) |
| Viewing Angle |
80/80/80/80 (Typ.)(CR≥10) (L/R/U/D) |
| Frequency |
60Hz |
| Lamp Type |
2 pcs CCFL Without Driver |
| Signal Interface |
LVDS (1 ch, 8-bit) , 20 pins |
| Input Voltage |
3.3V (Typ.) |
TMS150XG1-10TB Mechanical Features
| Dot Resolution |
1024(RGB)×768 (XGA) |
| Pixel Configuration |
RGB Vertical Stripe |
| Pixel Density |
85 PPI |
| Aspect Ratio |
4:3 (H:V) |
| Form Factor |
Flat Rectangle Display |
| Dot Pitch |
0.099×0.297 mm (H×V) |
| Pixel Pitch |
0.297×0.297 mm (H×V) |
| Weight |
1.00Kgs (Typ.) |
| Surface |
Antiglare |
| Active Area |
304.128×228.096 mm (H×V) |
| Bezel Area |
307.4×231.3 mm (H×V) |
| Outline Dimension |
326.5×253.5 mm (H×V) |
| Outline Depth |
11.3/12.0 (Typ./Max.) mm |
| Holes & Brackets |
Side mounting holes (4-M3) on left, right bezel |
| Landscape or Portrait |
Landscape type |
| Touch Panel |
Without |
FAQ
Q1: What's price?
A1: We provide reasonable price and recommend suitable batteries to our customers.
Q2: What's delivery time?
A2: The delivery time is normally 1-3 working days after payment.
Q3: What's the payment?
A3: We accept T/T, Western Union, MoneyGram, Paypal
Q4: Can we visit your factory?
A4: Warmly welcome. Once we have your schedule, we will arrange professional sales team to follow up
your case.
Packaging & Delivery
Packaging Details: Safe & Professional packing or as requirement for the LCD Screen replacements.
Delivery Detail: 2-3 days after receipt of payment
Payment terms: We accept T/T, PayPal, Western Union and others.
Below are our other LCD panels stock for your easy reference:
| Panel Model |
Brand |
Size |
Resolution |
| TM240160XCFWGRA |
Tianma |
2.2" |
240×160 |
| TM128128F6CCWGWC1 |
Tianma |
1.44" |
128×128 |
| TM12864G3CCWGWA-1 |
Tianma |
2.4" |
128×64 |
| TM050XYSP02 |
Tianma |
5.0" |
540×960 |
| TM050JYHN11-00 |
Tianma |
5.0" |
720×1280 |
| TM055JYSP08 |
Tianma |
5.5" |
720×1280 |
| TM040XYHP01 |
Tianma |
4.0" |
640×1136 |
| TM055JYSP03 |
Tianma |
5.5" |
720×1280 |
| TM055JYHP03 |
Tianma |
5.5" |
720×1280 |
We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk
