3.5 inch Tianma TM035HBHT6 LCM 240×320 80nits WLED TTL 50pins

Product Categories
N&S ELECTRONIC CO., LIMITED
Contact Now

3.5 inch Tianma TM035HBHT6 LCM 240×320 80nits WLED TTL 50pins

Brand Name : Tianma

Model Number : TM035HBHT6

Certification : ISO9001

Place of Origin : Japan

MOQ : 1

Payment Terms : T/T, Western Union,paypal

Supply Ability : 100 PCS / DAY

Delivery Time : 2-3 working days after payment confirmation

Packaging Details : Antistatic bag, Bubble Bag, Foam Box and Carton Box.

Series : TM035HBHT

Keywords Desc. : Tianma 3.5" LCM 240×320 80nits WLED TTL 50pins

Product Class : Graphic LCD Display

Product Tags : Color TFT-LCD,Resistive Touch LCD,Transflective LCD,Sunlight Readable

Application : Handheld Product

Panel Type : a-Si TFT-LCD

Panel Composition : LCM

Panel Size : 3.5"

Resolution : 240×320

Aspect Ratio : 3:4 (W:H)

Form Factor : Flat Rectangle Display

Orientation : Portrait type

Active Area : 53.64 (W) × 71.52 (H) mm (A.A)

Outline Dimension : 64 (W) × 85 (H) mm

Max. Depth : 4.43 mm

Weight : 44.4g

Polarizer : Transflective

Brightness : 80 (Typ.)

Contrast Ratio : 150:1 (Typ.)

Viewing Angle : 40/45/55/40 (Typ.)(CR10) (L/R/U/D)

Contact Now

3.5 inch Tianma TM035HBHT6 LCM 240×320 80nits WLED TTL 50pins

TM035HBHT6 General Features

Panel Brand :TIANMA
Panel Model :TM035HBHT6
Panel Type :a-Si TFT-LCD , LCM
Panel Size :3.5 inch
Resolution :240(RGB)×320 , QVGA
Display Mode :ECB, Normally White, Transflective
Active Area :53.64×71.52 mm
Outline :64×85×4.43 mm
Surface :Hard coating
Brightness :80 cd/m2 (Typ.)
Contrast Ratio :150:1 (Typ.)(Transmissive) 2.5:1 (Typ.)(Reflective)
Display Colors :262K (6-bit) , CIE1931 37%
Response Time :35 (Typ.)(Tr+Td)
Viewing Angle :40/45/55/40 (Typ.)(CR≥10) (L/R/U/D)
Lamp Type :6S1P WLED
Signal Interface :Parallel RGB (1 ch, 6-bit) + SPI , 50 pins
Input Voltage :2.8/15.0/-10.0V (Typ.)(VCC/VGH/VGL)

TIANMA TM035HBHT6 Mechanical Features

Panel Size :3.5 inch
Dot Resolution :240(RGB)×320 (QVGA)
Pixel Configuration :RGB Vertical Stripe
Pixel Density :113 PPI
Aspect Ratio :3:4 (H:V)
Form Factor :Flat Rectangle Display
Dot Pitch :0.0745×0.2235 mm (H×V)
Pixel Pitch :0.2235×0.2235 mm (H×V)
Weight :44.4g
Surface :Hard coating
Active Area :53.64×71.52 mm (H×V)
Outline Dimension :64×85 mm (H×V)


What is our advantage?
Factory Experience: More than 6 years of experience in the agency & sourcing line of Hard-to-find LCD Screen replacements.
Delivery Quantity: 50-100 cartons shipped by DHL every week
Supply Ability: 100 pcs Panels per day.
Supply Area: All over the word (Most of North America, South America, Europe, Japan, Korea and more.)
Warranty: 12 months.

FAQ
Q1: Can I place sample order first?
A1: Yes, we will quote you different prices for small, medium and large qty. You can order with different price for different qty.
Q2: How could I pay them?
A2: We accept T/T, Western Union, MoneyGram, Paypal.
Q3: How to place the order?
A3: Please send us your purchase order by e-mail, whatsapp or Skype or you can ask us to send you a Proforma Invoice for your order.
Q4: How long can I get my order?
A4: For samples, we will finish production and ship within 1-3 working days. For bulk orders, that will base on the order quantity.
Q5: How to send us the products?
A5: We usually use DHL, UPS, FedEx to ship our LCD screen replacements to our clients.

Here comes our other LCD panels stock for your easy reference:
Pls contact to us for more stock information: salespm@nselectronic.com.hk

Panel ModelBrandSizeResolution
TM240160XCFWGRATianma2.2"240×160
TM128128F6CCWGWC1Tianma1.44"128×128
TM12864G3CCWGWA-1Tianma2.4"128×64
TM050XYSP02Tianma5.0"540×960
TM050JYHN11-00Tianma5.0"720×1280
TM055JYSP08Tianma5.5"720×1280
TM040XYHP01Tianma4.0"640×1136
TM055JYSP03Tianma5.5"720×1280
TM055JYHP03Tianma5.5"720×1280
TM055JYHP01Tianma5.5"720×1280


TM035HBHT6 Picture

3.5 inch Tianma TM035HBHT6 LCM 240×320 80nits WLED TTL 50pins
