LMG7420PLFC-X Hitachi LCD Panel 5.0 inch for Industrial Application for 75Hz
LMG7420PLFC-X Specification
| Panel Model | LMG7420PLFC-X |
|---|
| Panel Brand | HITACHI |
|---|
| Descrition | FSTN-LCD ,5.1 inch, 240×128 |
|---|
| Panel Type | FSTN-LCD |
|---|
| Display Mode | STN, Black/White (Negative), Transmissive |
|---|
| Active Area | 119.97×63.97 mm |
|---|
| Outline | 159.4×101×12 mm |
|---|
| Surface | Antiglare, Hard coating (3H) |
|---|
| Contrast Ratio | 20:1 (Typ.) |
|---|
| Display Colors | Monochrome |
|---|
| Response Time | 160/110 (Typ.)(Tr/Td) |
|---|
| Viewing Angle | 40/40/40/40 (Typ.)(CR≥2) (L/R/U/D) |
|---|
| Frequency | 75Hz |
|---|
| Lamp Type | 1 pcs CCFL Without Driver |
|---|
| Signal Interface | 8-bit parallel , 20 pins |
|---|
| Input Voltage | 5.0V (Typ.) |
|---|
Up to now, over hundreds of aerospace, power management, network, communications, instrumentation and consumer electronics, etc are benefiting from our service and LCD screen panels.
We can do for you:
- Provide excellent LCD screen replacements with competitive price.
- Safe, quick and efficient supply chain.
- Plenty of stocks. Branded ones include LCD Screen panels for LG, Samsung, Sharp, BOE, Chimei and so on.
- Your problems will be replied within 24 hours.
LMG7420PLFC-X Basic Information
| Panel Model | LMG7420PLFC-X |
|---|
| Panel Brand | HITACHI |
|---|
| Descrition | FSTN-LCD ,5.1 inch, 240×128 |
|---|
| Panel Type | FSTN-LCD |
|---|
| Operating Temperature | 0 ~ 50 °C |
|---|
| Storage Temperature | -20 ~ 60 °C |
|---|
| Vibration Resistance | 2.0G (19.6 m/s²) |
|---|
| Remarks | Duty:1/128 |
|---|
FAQ
Q1: How do we place an order?
A1: Please kindly send us an email specifying the item No., replacements, quantity, other specifications for the Hard disk to place an order.
Q2: How do we make the payment?
A2: We accept T/T, Western Union, MoneyGram, Paypal.
Q3: What's the delivery time?
A3: The delivery time is normally 1-3 working days after payment.
Q4: How would the goods be shipped?
A4: We ship via DHL, UPS, TNT and others.
LMG7420PLFC-X Mechanical Features
| Dot Resolution | 240×128 |
|---|
| Pixel Configuration | Rectangle |
|---|
| Pixel Density | 50 PPI |
|---|
| Aspect Ratio | 17:9 (H:V) |
|---|
| Form Factor | Flat Rectangle Display |
|---|
| Dot Pitch | 0.50×0.50 mm (H×V) |
|---|
| Pixel Pitch | 0.50×0.50 mm (H×V) |
|---|
| Weight | 180g (Typ.) |
|---|
| Surface | Antiglare, Hard coating (3H) |
|---|
Below are our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| HX7308BTJFA | Himax | 0.45" | 1024×768 |
| HX7027ATGFA | Himax | 0.44" | 640×480 |
| HX7019ATGFA | Himax | 0.38" | 640×360 |
