LM190E08-TLGE LG LCD Panel LG Display 19.0 inch LCM Normally White
After-sale Services:
1)warranty for 1 year, 7 days return for the non-working items, except broken, crashed cargo (Buyer pay for return shipping fee).
2)Please make sure the item is compatible for your model before ordering. No return for incompatible issues.
3)When you receive the item,if you find the box is break and the goods break. Please take photo about the goods and refuse accepting the goods .Please contact me and sent photo of product to me as soon as possible .I will complaint the delivery company.
What’s our advantage compared with other suppliers?
(1). Before shipment, we will test every LCD Screen and ensure the quality.
(2). we provide high quality lcd panels for customers all over the world.
(3) .We have DBS, ISO9001 Certifications for our Panels.
(4) .Excellent service on before-sale, on-sale and after-sale.
LM190E08-TLGE Information
Panel Size :
| |
19.0 |
| Dot Resolution : |
1280(RGB)×1024 (SXGA) |
| Pixel Configuration : |
RGB Vertical Stripe |
| Pixel Density : |
86 PPI |
| Aspect Ratio : |
5:4 (H:V) |
| Form Factor : |
Flat Rectangle Display |
| Dot Pitch : |
0.098×0.294 mm (H×V) |
| Pixel Pitch : |
0.294×0.294 mm (H×V) |
| Weight : |
1.95/2.05Kgs (Typ./Max.) |
| Surface : |
Antiglare, Hard coating (3H) |
| Active Area : |
376.32×301.056 mm (H×V) |
| Bezel Area : |
380.3×305.0 mm (H×V) |
| Outline Dimension : |
396×324 mm (H×V) |
| Outline Depth : |
12.1/16.0 (Typ./Max.) mm |
| Holes & Brackets : |
Side mounting holes (4-M3) on left, right bezel |
| Landscape or Portrait : |
Landscape type |
| Touch Panel : |
Without |
Display Mode :
| |
TN, Normally White, Transmissive |
| Brightness : |
300 cd/m² (Typ.) |
| Contrast Ratio : |
800 : 1 (Typ.) (Transmissive) |
| Display Color : |
16.7M (6-bit + Hi-FRC) |
| Response Time : |
1.3/3.7 (Typ.)(Tr/Td) |
| Viewing Angle : |
85/85/75/85 (Typ.)(CR≥10) (L/R/U/D) |
| Viewing Direction : |
6 o'clock |
| White color Chromaticity : |
Wx:0.313; Wy:0.329 |
| White Variation : |
1.33 (Max.)(9 points) |
| Sunlight Readable : |
y |
Below are our other LCD panels stock for your easy reference:
| Panel Model |
Brand |
Size |
Resolution |
| LB060S01-FD01 |
LG Display |
6.0" |
800×600 |
| LD470DUJ-SFE2 |
LG Display |
47" |
1920×1080 |
| LC650EQK-FGK1 |
LG Display |
65" |
3840×2160 |
| LH470M01-SH01 |
LG Display |
4.7" |
540×960 |
| LH250Q01-TH03 |
LG Display |
2.5" |
320×240 |
| LH320H02-SH03 |
LG Display |
3.2" |
320×480 |
We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk
