Original 12.1 inch LP121WX4-TLA1 for 1280*800, without touch screen monitor

Product Categories
N&S ELECTRONIC CO., LIMITED
Contact Now

Original 12.1 inch LP121WX4-TLA1 for 1280*800, without touch screen monitor

  • 1
  • 2

Brand Name : LG LCD Panel

Model Number : LP121WX4-TLA1

Certification : ISO9001

Place of Origin : Japan/Taiwan

MOQ : 1 piece

Payment Terms : T/T, Western Union,paypal

Supply Ability : 1000 PCS PER DAY

Delivery Time : 1-3 Working Days

Packaging Details : Antistatic bag, Bubble Bag, Foam Box and Carton Box.

Panel Size : 12.1 inch

Resolution : 1280(RGB)×800 , WXGA

Display Colors : 262K (6-bit)

Input Voltage : 3.3V (Typ.)

Brightness : 250 cd/m² (Typ.)

Model Alias : LP121WX4 (TL)(A1)

Contact Now

Original 12.1 inch LP121WX4-TLA1 for 1280*800, without touch screen monitor

Application

  • Industrial display application
  • handheld devices

Specifications

Panel Size : 12.1 inch
Dot Resolution : 1280(RGB)×800 (WXGA)
Pixel Configuration : RGB Vertical Stripe
Pixel Density : 125 PPI
Aspect Ratio : 16:10 (H:V)
Form Factor : Flat Rectangle Display
Dot Pitch : 0.0676×0.2028 mm (H×V)
Pixel Pitch : 0.2028×0.2028 mm (H×V)
Weight : 145/155g (Typ./Max.)
Surface : Antiglare
Active Area : 259.594×162.24 mm (H×V)
Bezel Area : 264.6×166.6 mm (H×V)
Outline Dimension : 270.6×187.5 mm (H×V)
Outline Depth : 2.95/3.45 (Max.) mm
Holes & Brackets : Without
Landscape or Portrait : Landscape type
Touch Panel : Without

Display Mode : TN, Normally White, Transmissive
Brightness : 250 cd/m² (Typ.)
Contrast Ratio : 250 : 1 (Min.) (Transmissive)
Display Color : 262K (6-bit)
Response Time : 25 (Typ.)(Tr+Td)
Viewing Angle : 45/45/15/35 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction : 6 o'clock
White color Chromaticity : Wx:0.313; Wy:0.329
White Variation : 1.33/1.67 (Max.)(5/13 points)

General Features

Panel Brand : LG Display
Panel Model : LP121WX4-TLA1
Panel Type : a-Si TFT-LCD , Panel
Panel Size : 12.1 inch
Resolution : 1280(RGB)×800 , WXGA
Display Mode : TN, Normally White, Transmissive
Active Area : 259.594×162.24 mm
Outline : 270.6×187.5×3.45 mm
Surface : Antiglare
Brightness : 250 cd/m² (Typ.)
Contrast Ratio : 250:1 (Min.)
Display Colors : 262K (6-bit)
Response Time : 25 (Typ.)(Tr+Td)
Viewing Angle : 45/45/15/35 (Typ.)(CR≥10) (L/R/U/D)
Frequency : 60Hz
Lamp Type : 6 strings WLED Embedded (LED Driver)
Signal Interface : LVDS (1 ch, 6-bit) , 30 pins
Input Voltage : 3.3V (Typ.)

Company Information:
ShenZhen N&S Technology CO., LTD was established in 2010, Speciliazed in the LCD product development / production, we holds the operating philosophy of "quality, service, responsibility, innovation".

Our products have passed the certification of ISO9001 Quality Management Systemin order to improve quality of our products.

We have a wealth of professional experience and strong research and development, always walk in the forefront of the industry in the fierce market competition, with unremitting efforts to achieve development!

Here comes our other LCD panels stock for your easy reference:

Pls contact to us for more stock information: salespm@nselectronic.com.hk

Panel Model Brand Size Resolution
LH550WF3-SH01 LG Display 5.5" 1080×1920
LC320DXY-SHA3 LG Display 31.5" 1366×768
LC490EQL-SHA2 LG Display 49" 3840×2160
LC430EQL-SHA2 LG Display 43" 3840×2160
LC430DUY-SHA2 LG Display 43" 1920×1080
LC550EGY-SHM2 LG Display 55" 3840×2160
LC320DXJ-SFA9 LG Display 31.5" 1366×768
LH400WV3-SD06 LG Display 4.0" 480×800
LH300Q02-SD01 LG Display 3.0" 240×320
