Below are our other LCD panels stock for your easy reference:
| Panel Model |
Brand |
Size |
Resolution |
| ED312TT2 |
E Ink |
31.2" |
2560×1440 |
| ES133TE1 |
E Ink |
13.3" |
2200×1650 |
| ES133TT2 |
E Ink |
13.3" |
2200×1650 |
| ED133TT1 |
E Ink |
13.3" |
2200×1650 |
| ED060SD1 |
E Ink |
6.0" |
600×800 |
We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk
PVI LCD Display PD057VU5 5.7 inch 115.2×86.4 mm Active Area 144×104.6×13.3 mm Outline
The reasons you choose us
1).More competitive price! As aprofessional LCD Distributor,we have our own souring lines &solutions to support us for the more competitive service, not only the price, but also the stock for the hard-to-find LCD panels.
2).Great quality! All LCD Screen we sent are with good quality guarantee,100% quality check and full one year warranty!
3).Fast delievery! Delivery time will be faster than others.
4).Great shipping service! We have cooperated with DHL,UPS and EMS for long time,so we could promise save much more money on the shipping cost and betterservice is offered!
5).Best sale-service!Professional team to service with you before sale, on sale & after service.
PVI PD057VU5 General Features
| Panel Brand : |
PVI |
| Panel Model : |
PD057VU5 |
| Panel Type : |
a-Si TFT-LCD , Panel |
| Panel Size : |
5.7 inch |
| Resolution : |
320(RGB)×240 , QVGA |
| Display Mode : |
TN, Normally White, Transmissive |
| Active Area : |
115.2×86.4 mm |
| Outline : |
144×104.6×13.3 mm |
| Surface : |
Antiglare |
| Brightness : |
700 cd/m² (Typ.) |
| Contrast Ratio : |
600:1 (Typ.) |
| Display Colors : |
262K (6-bit) |
| Response Time : |
15/25 (Typ.)(Tr/Td) |
| Viewing Angle : |
60/60/40/50 (Typ.)(CR≥10) (L/R/U/D) |
| Frequency : |
60Hz |
| Lamp Type : |
3S12P WLED |
| Signal Interface : |
TTL (1 ch, 6-bit) , 33 pins |
| Input Voltage : |
3.3V (Typ.)(VCC) |
PVI PD057VU5 Optical Features
| Display Mode : |
TN, Normally White, Transmissive |
| Brightness : |
700 cd/m² (Typ.) |
| Contrast Ratio : |
600 : 1 (Typ.) (Transmissive) |
| Display Color : |
262K (6-bit) |
| Response Time : |
15/25 (Typ.)(Tr/Td) |
| Viewing Angle : |
60/60/40/50 (Typ.)(CR≥10) (L/R/U/D) |
| White color Chromaticity : |
Wx:0.310; Wy:0.340 |
| White Variation : |
1.17/1.25 (Typ./Max.)(9 points) |
Our Service
• Long lasting product cycle for continuity thru all phases of project rollouts and servicing
• Easy-to-install console, Open Frame chassis-mount display
• Slim dimensions enable better enclosure designs
• Multiple mounting options.
• All steel construction provides rugged frame for public use environments
• Two independent touch points
• Improved power efficiency and reduced consumption
• ISO9001 approvals.
