Samsung LCD Panel LTN097XL01-H01 210.42×166.42×5.8 mm Outline 196.608×147.456 mm Active Area
Company Strength
1. ISO9001 certificated, Factory Direct Supplied
2. RoHS Compliant, Lead Free, Reach Compliant
3. Competitive Price and Short Lead-time
4. Professional Team with Rich Experiences in Design/Mfg/Quality Control
5. Small MOQ Support & Fast Response to Customers
6. Long Product Life Time
SAMSUNG LTN097XL01-H01 General Features
| Panel Brand : | SAMSUNG |
| Panel Model : | LTN097XL01-H01 |
| Panel Type : | a-Si TFT-LCD , Panel |
| Panel Size : | 9.7 inch |
| Resolution : | 1024(RGB)×768 , XGA |
| Display Mode : | PLS, Normally Black, Transmissive |
| Active Area : | 196.608×147.456 mm |
| Outline : | 210.42×166.42×5.8 mm |
| Surface : | Glare (Haze 0%), Hard coating (3H) |
| Brightness : | 300 cd/m² (Typ.) |
| Contrast Ratio : | 600:1 (Typ.) |
| Display Colors : | 262K (6-bit) |
| Response Time : | 30 (Typ.)(Tr+Td) |
| Viewing Angle : | 80/80/80/80 (Min.)(CR≥10) (L/R/U/D) |
| Frequency : | 60Hz |
| Lamp Type : | 6S6P WLED |
| Signal Interface : | LVDS (1 ch, 6-bit) , 30 pins |
| Input Voltage : | 3.3V (Typ.) |
Packing & Delivery for our LCD Screen Panel Replacements
1. Anti-static Bag Packing.
2. Anti-Shock Bubble Bag Packing
3. Foam and Hard Carton Packing
4. Picked up by forward and delivered by express services.
SAMSUNG LTN097XL01-H01 Optical Features
| Display Mode : | PLS, Normally Black, Transmissive |
| Brightness : | 300 cd/m² (Typ.) |
| Contrast Ratio : | 600 : 1 (Typ.) (Transmissive) |
| Display Color : | 262K (6-bit) |
| Response Time : | 30 (Typ.)(Tr+Td) |
| Viewing Angle : | 80/80/80/80 (Min.)(CR≥10) (L/R/U/D) |
| Viewing Direction : | Symmetry |
| White color Chromaticity : | Wx:0.313; Wy:0.329 |
| White Variation : | 1.40/1.70 (Typ./Max.)(13 points) |
Details Pictures for Samsung LCD Panel LTN097XL01-H01
